Note : Check 3D Hologram on Firestop Fire Extinguishers for Genuineness.
| PERFORMANCE DATA | Download Technical Datasheet | ||||
|---|---|---|---|---|---|
| MODEL | FEP1 | FEP2 | FEP4 | FEP6 | FEP9 |
| Capacity (In Kgs.) | 1 | 2 | 4 | 6 | 9 |
| Fire Rating | 1A & 8B | 1A & 13B | 2A & 21B | 3A | 4A |
| Average Discharge Time | 9 sec | 13 sec | 18 sec | 20 sec | 26 sec |
| Height (Approx.) | 34.00 cm | 37.00 cm | 48 cm | 59 cm | 60 cm |
| Diameter (Approx) | 86.5 mm | 108 mm | 130 mm | 150 mm | 175 mm |
| Gross Weight (Approx.) | 2 Kg | 3.5 Kg | 6.5 Kg | 9 Kg | 14 Kg |
| Operating Temperature Range | -10°C TO +55C | ||||
| Service Pressure | 15 bar | ||||
| Maximum Service Pressure | 16.5 bar | ||||
| Test Pressure | 35 bar | ||||
| Certification | BIS (ISI) | ||||
Firestop fire extinguishers are guaranteed against any manufacturing defects.
Design & specification may be changed without notice in view of technical upgradation.
